Ensure Proper Protection of Your Cargo or Belongings
In the world of agriculture, transporting cargo can involve a variety of equipment, from tractors to tiles and pallets of seed. To ensure the safety of these goods during transit, it's essential to adhere to cargo securement guidelines set by the Federal Department of Transportation's Federal Motor Carrier Safety Association.
For cargo that is 10 feet long and weighs more than 1,100 pounds, the number of tie-downs required is determined by both weight and length regulations for secure transport. Specifically, cargo weighing between 1,000 and 1,499 pounds requires at least 2 tie-downs. Since a 10-foot cargo weighs over 1,100 pounds but less than 1,500 pounds, a minimum of 2 tie-downs is necessary.
The number of tie-downs per 10 feet of cargo length is typically one. However, in this case, the 2 tie-down minimum based on weight still applies. It's important to note that each tie-down strap used should have a Working Load Limit (WLL) sufficient to secure the load. For example, straps with a WLL of 700 lbs can be used in pairs for a cargo weighing over 1,100 lbs, as 2 straps would cover 1,400 lbs working load.
When hauling equipment, it's recommended to tie-down attachments such as front-end loader buckets, backhoe attachments, and blades on either the front or back of equipment. It's also advisable that the total WLL of all used tie-downs must equal at least half of the cargo's weight.
When hauling a load, it's crucial to complete a pre-trip inspection. This includes checking the trailer tire pressure, lug nuts, hitch and locking mechanism, electrical and brake system, lights and turn signals, chains and straps, trailer floor, and cargo.
There are two proper methods to tie-down loads: directly to a manufactured anchored point on the trailer or through, over, or around the cargo to another manufactured trailer point (indirect tie-down). The grain of the wood used for chocks, wedges, or braces should run lengthwise.
To prevent cargo from rolling, place a chock or wedge slightly under the edge of the cargo, making sure it is secured to the trailer. To prevent sliding or shifting of equipment or cargo, consider using blocking, bracing, or friction mats.
If the cargo has a tendency to tip, use a brace. Four tie-downs (at least) are needed for cargo weighing over 10,000 pounds. When using wood for a chock, wedge, or brace, hardwood is recommended, properly seasoned, and free from rot or decay, knots, and splits.
It's recommended to place the weight of the load in the center of the trailer or cargo area by using an "X" pattern for the tie-downs, pulling them tight against each other and keeping the load secured in the center. Two tie-downs are needed for cargo 5 feet or less in length and more than 1,100 pounds in weight.
There is no maximum number of tie-downs when securing a load. When hauling a load at speeds greater than 25 mph, it's recommended to cover or remove the Slow Moving Vehicle (SMV) emblem.
By following these guidelines, you can ensure your cargo is properly secured during transportation, thereby complying with safety regulations.
